Inclusion casting technique using moulds

Made by : Perles & Co
Published on the :07/10/2015
Inclusion casting technique using moulds

You can use castin resin with a mould, to cast for example
beads or charms in a cabochon.


Material and advice:
A mold, Bijoux inclusion fantaisie n°2.
Casting resin, and the chemist kit for casting resin, will be helpful to work.
In the example below we use 5 2 hole beads 15x6mm Dyed of different colours.


resine_cabochon


Step 1:

Mix 1 portion of hardener with 2 portions of casting resin,
shake the mix gently to avoid bubbles.
Pour the mix into a bottle with precision tip.
Pour some millimiters of the mixture into the mould.

resine_cabochon_1

Step 2:

Let the resin dry for some hours, it must be hard enough,
even if it is still a bit sticky.
Once the resin is dry place the 2 hole beads.

resine_cabochon_2

Step 3:

Mix 1 portion of hardener with 2 portions of casting resin,
shake the mix gently to avoid bubbles.
Pour the mix into a bottle with precision tip.
Pour the resin onto the beads.

resine_cabochon_3


Step 4:

You can pierce bubbles with a needle if necessary.

resine_cabochon_4

Step 5:

After 48 hours drying, you can unmold the cabochon.
You can smooth the edge of the cabochon for a better finish.

resine_cabochon_6

Step 6:

Let dry away from the sun during 15 days to get a complete polimerization.
resine_cabochon_7

Advice for use:

Do not hesitate to let dry the first layer of resin during a long time,
to avoid the beads from sinking.

Respect the conservation temperatures so the products do not alter.

Use quickly the cast resin and the hardener, because they alter in time, even if they are not mixed and if you keep them away from light.
You can use alterated products, but drying time will be much longer.

Tutorial steps

Step 1
Inclusion casting technique using moulds : Step 1

Mix a small amount of resin according to the instructions (one part hardener, two parts resin).
Stir the mixture gently to avoid the formation of bubbles, then transfer it into an empty bottle with a precision nozzle.
Pour a first layer of resin of a few millimeters into the mold.

resine_cabochon_1

Step 2
Inclusion casting technique using moulds : Step 2

Let it dry for a few hours, the resin can be sticky, but quite hard.
Once the resin is dry, place your resin elements.

Tips: Don't hesitate to let the resin dry longer (especially the first layer, because otherwise the elements you are going to include will sink).

resine_cabochon_2

Step 3
Inclusion casting technique using moulds : Step 3

Make a second mixture of resin, in larger quantity to be able to fill the mould, by respecting the dosages indicated on the instructions.
Transfer the mixture into the bottle with precision nozzle.
Pour the resin on the elements to be resinated.

resine_cabochon_3

Step 4
Inclusion casting technique using moulds : Step 4

Use a needle to pierce any bubbles that may form in the holes of the bars.

resine_cabochon_4

Step 5
Inclusion casting technique using moulds : Step 5

After 48 hours of drying, you can remove the cabochon from the mold.
For a better finish, file the edges of the cabochon.

resine_cabochon_6

Step 6
Inclusion casting technique using moulds : Step 6

For a definitive polymerization, let dry 15 days in a dark place.

resine_cabochon_7
